Item

Spec

Aircraft

Weight

1.375 g

Diagonal Size (Propellers Excluded)

350 mm

Operating Temperature

0°C to 40°C

Storage Temperature

0°C to 40°C

Gimbal

Angular Vibration Range

±0.02°

Mount

Detachable

Controllable Range

Pitch: -90° to +30°

Stabilization

3-axis (pitch, roll, yaw)

Camera

Sensor

1-inch CMOS 20MP

Lens

FOV 84° 8.8 mm/24 mm (35 mm format equivalent)

f/2.8-f/11 auto focus at 1 m-∞

Exposure Mode

Auto, Manual

Mechanical Shutter Speed

8 - 1/2000 s

Electronic Shutter Speed

1 - 1/8000 s

ISO Range

Video: 100 - 6400
Photo: 100 - 12800

Video Resolution

4096×2160 24/25/30p @100Mbps

Video Format

MP4/MOV (AVC/H.264; HEVC/H.265)

Video subtitles

Supported

Photo Size

5472×3648

Photo Format

JPEG, DNG (RAW), JPEG + DNG

Remote Controller

Operating Frequency

2.400 - 2.483 GHz and 5.725 - 5.850 GHz

Max Transmission Distance

2.400-2.483 GHz, 5.725-5.850 GHz (Unobstructed, free of interference)

FCC: 10000 m

CE: 6000 m

SRRC: 6000 m

MIC: 6000 m

Operating Temperature Range

0°C to 40°C

Transmitter Power (EIRP)

2.400-2.483 GHz

FCC: 26 dBm

CE: 20 dBm

SRRC: 20 dBm

MIC: 17 dBm

5.725-5.850 GHz

FCC: 26 dBm

CE: 14 dBm

SRRC: 20 dBm

MIC: -

Operating Current/Voltage

1.2 A@7.4 V

Video Output Port

GL300K: HDMI GL300L: USB

Mobile Device Holder

GL300L: Tablets and smart phones

Charger

Voltage

17.4 V

Rated Power

100 W

Features

Mobile App

DJI GO 4

Live View Working Frequency

2.4 GHz ISM, 5.8 GHz ISM

Live View Quality

720P @ 30fps, 1080P @ 30fps

Latency

Phantom 4 Pro+ V2.0: 160-180 ms
Phantom 4 Pro V2.0: 220 ms (depending on conditions and mobile device)

Storage

Supported SD Card

MicroSD card (Max capacity: 128 GB，UHS-1 Speed Grade 3 required)

Supported File Systems

FAT32 (≤ 32 GB), exFAT (> 32 GB)

Recommended Micro SD Cards

TOSHIBA EXCERIA PRO 32GB micro SD HC SanDisk_Extreme PRO_32GB_3_A1_micro SD V30 HC TOSHIBA EXCERIA PRO 64GB micro SD XC SanDisk_Extreme PRO_64GB_3_A2_micro SD V30 XC SAMSUNG_EVO_128GB_micro SD 3 XC
TOSHIBA EXCERIA M303E 32GB micro SD HC
TOSHIBA EXCERIA M303E 64GB micro SD XC
TOSHIBA EXCERIA M303E 64GB micro SD XC
TOSHIBA EXCERIA M303 128GB micro SD XC SAMSUNG_EVO_64GB_micro SD 3 XC
